Standard Features
- High performance carriage
- Fail-safe rebound brakes
- Full safety guard system
- Self- contained shock dampening system
Optional Features
- Half – sine programmers
- Low impulse kit
- Square wave programmers
- Data analysis and acquisition systems
- Terminal peak sawtooth programmers
- Automatic cycle counter
- Dual mass shock amplifier
- Fixturing
| METRIC | ENGLISH | METRIC | ENGLISH | METRIC | ENGLISH | |
|---|---|---|---|---|---|---|
| Machine Type | SD-10 | SD-16 | SD-24 | |||
| Size | 254 x 254 mm | 10 x 10 in | 406 x 406 mm | 16 x 16 in | 610 x 610 mm | 24 x 24 in |
| Test Load Rating | 14 kg | 30 lbs | 91 kg | 200 lbs | 181 kg | 400 lbs |
| Carriage Weight | 20 kg | 45 lbs | 77 kg | 170 lbs | 245 kg | 540 lbs |
| Mounting Hole Pattern | M6x1 – 50 mm Grid | M8x1.25 – 75 mm Grid | M10x1.25 – 100 mm Grid | |||
| Standard Carriage Fall | 1067 mm | 42 in | 1524 mm | 60 in | 1524 mm | 60 in |
| Optional Carriage Fall | *** Consult Factory *** | |||||
| Maximum Acceleration | 3500 G | 1500 G | 1000 G | |||
| Minimum Pulse Duration | 0.3 ms | 0.5 ms | 1 ms | |||
| Isolated Base Weight | 228 kg | 500 lbs | 952 kg | 2100 lbs | 1497 kg | 3300 lbs |
| Floor Space Required | 305 x 635 mm | 12 x 25 in | 686 x 838 mm | 27 x 33 in | 1219 x 1219 mm | 48 x 48 in |
| Machine Overall Height | Selected Carriage Fall | Selected Carriage Fall | Selected Carriage Fall | |||
| Plus 1321 mm | Plus 52 in | Plus 1549 mm | Plus 61 in | Plus 1829 mm | Plus 72 in | |
| Shipping Weight | 431 kg | 950 lbs | 1588 kg | 3500 lbs | 2495 kg | 5500 lbs |
| Standard Power Inputs | 110-230V / 1PH / 50 or 60 Hz | |||||
